230W mini beam moving head light
HM-M230W-1
Total power: 360W, lighter and more convenient in the same power range
Channel: 16CH
Control effect: DMX512, self running built-in program, voice control
Bulb type: Uden/OSRAM 230W with a luminous flux of 15000lm and a color temperature of up to 7500K
Pattern: 13 images+1 white light, shaking, flowing effect
Color: 14 colors+white light
Strobe: 1-11 times/second
Prism: 8+16+24 Prism rotatable function
Channel: 16CH
Control effect: DMX512, self running built-in program, voice control
Bulb type: Uden/OSRAM 230W with a luminous flux of 15000lm and a color temperature of up to 7500K
Pattern: 13 images+1 white light, shaking, flowing effect
Color: 14 colors+white light
Strobe: 1-11 times/second
Prism: 8+16+24 Prism rotatable function
Quantity:
Description:
● Homei Stage Lighting 230W sharpy beam moving head light,bulb lifetime more than 5000 hours
● Prism: 8+16+24 prism. can rotate independently in both directions
●With 1 fixed pattern plate of 13 fixed patterns+ white
● one color wheel, 14 colors + white
●Fast strobe, multi-strobe mode selection, synchronization, bisection, random;
●Menu display: 2.8-inch LCD touch screen + buttons, Chinese and English languages can be switched at will, fonts can be automatically displayed in reverse 180 degrees
●Fast strobe, multi-strobe mode selection, synchronization, bisection, random;
●Menu display: 2.8-inch LCD touch screen + buttons, Chinese and English languages can be switched at will, fonts can be automatically displayed in reverse 180 degrees
| Input Voltage | AC110V-240V / 50-60Hz |
| Light Source Specification | 230W |
| Light Source Life | 5,000 hours |
| Lumen Illuminance | 5w lm at 5 meters |
| Rated Power | 450W |
| Channel Mode | 16channels |
| Horizontal Scan | 540 degrees (16-bit precision scan), electronic error correction |
| Vertical Scanning | 270 degrees (16-bit precision scanning), electronic error correction |
| Dimming System | 0-100% linear adjustment |
| Focusing System | Linear adjustment from 4 meters to 50 meters |
| Atomization System | Independent atomization effect, soft and natural light spot |
| Magnification Angle | 1.8 degrees |
| High-Speed Strobe | 0-30 times/sec, adjustable speed strobe effect, strobe macro function |
| Color | 14 colors + white light |
| Fixed Gobos | 13 fixed patterns + white light |
| Prism System | Standard single 8-row prism and 8+16+24 prism, each can be independently rotated forward and reverse |
| Macro Function | Console reset function, self-propelled mode, master-slave mode |
| Display Mode | LCD, key + touch dual operation mode |
| Control Signal | International standard DMX512, with RDM function, online software upgrade available, dial address code |
| Cooling Method | Axial fan to enhance cooling |
| Safety Device | Electronic temperature control overheating protection, automatic power-off protection when the overheating system fails |
| Appearance Material | High-temperature resistant plastic |
| Working Environment | -20°C to 40°C |
| Protection Level | IP20 |
| Gross Weight | 11 kg |
| Package Size | 26*24*45 cm (L × W × H) |
